SV-1232MG - Savox - Servo - Digital - High Voltage - Coreless Motor

Savox - Servo - SV-1232MG - Digital - High Voltage - Coreless Motor - Metal Gear

Savöx

SV-1232MG

not in stock

€ 71,95 € 59,46 excl. VAT

Servo - SV-1232MG - Digital - High Voltage - Coreless Motor - Metal Gear

The SV-1232MG servo is an extremely fast micro-sized servo ideal for 250-450 size helicopters where speed is essential.

Features:
• Metal gear train ensures durability and longevity.
• All metal case helps with cooler operating temperatures.
• Capable of high voltage use.
• Extremely fast for quick response.

Specifications:
• Torque @ 6v - 4.0kg
• Torque @ 7.4v - 5.0kg
• Speed @ 6v - 0.06 sec/60 deg
• Speed @ 7.4v - 0.05 sec/60 deg
• Dimensions L x W x H (mm): 23.0 x 12.0 x 27.3
• Weight: 23.0g

General Info

Item Nr: SV-1232MG

Barcode: 4710006992662

Brand: Savöx

Servo - Specs

Speed 60°/Sec @ 6.0V: 0,06

Speed 60°/Sec @ 7.4V: 0,05

Torque kg/cm @ 6.0V: 4

Torque kg/cm @ 7.4V: 5

Quiescent Current (mA): 5

Rated Current (mA): 180

Blocking Current (mA): 2200

Servo - Dimensions

Servo Type: Micro Servo

Spline Type: 21T Spline

Length (mm): 23

Width (mm): 12

Height (mm): 27,3

Weight (g): 23

Servo - Technology

Technology: Digital HV

Operating Voltage (V): 6.0V - 7.4V

Servo Motor: Coreless Motor

Servo Protection: Water - Dust Resistant

Servo Positioning: VR Potentiometer - Direct Drive

Servo Gears: Metal Gears

Servo Case: Aluminium Case

Connector: JR Universal + Colored Lead

Safety Documents:

SV-1232MG_CE_DeclarationForm_EN_12072017
