General Info

Item Nr

SB-2230SG

Barcode

4710006992112

Brand

Savöx

Servo - Specs

Speed 60°/Sec @ 4.8V

0,1

Speed 60°/Sec @ 6.0V

0,16

Speed 60°/Sec @ 7.4V

0,13

Speed 60°/Sec @ 8.4V

0,11

Torque kg/cm @ 4.8V

8

Torque kg/cm @ 6.0V

36

Torque kg/cm @ 7.4V

45

Torque kg/cm @ 8.4V

55

Quiescent Current (mA)

5

Rated Current (mA)

280

Blocking Current (mA)

10000

Servo - Dimensions

Servo Type

Standard Servo

Spline Type

25T Spline 6,0mm

Length (mm)

40,3

Width (mm)

20,2

Height (mm)

44,9

Weight (g)

84

Servo - Technology

Technology

Digital HV

Operating Voltage (V)

6.0V - 8.4V

Servo Motor

Brushless Motor

Servo Protection

Water - Dust Resistant

Servo Positioning

VR Potentiometer - Direct Drive

Servo Gears

Steel Gears

Servo Case

Aluminium + Composite Case

Connector

JR Universal + Colored Lead
