Savox - Servo - SB-2283MG - Digital - High Voltage - Brushless Motor

Savox - Servo - SB-2283MG - Digital - High Voltage - Brushless Motor - Metal Gear

Savöx

SB-2283MG

>10 in stock

€ 124,95 € 112,46

€ 92,94 excl. VAT

Servo - SB-2283MG - Digital - High Voltage - Brushless Motor - Metal Gear

Features:
• Leading edge digital servo technology
• High efficiency Brushless motor
• Accurate and fast response
• Super high resolution
• Aluminium case for improved motor cooling and total strength
• Ball beared
• Precision Metal gears

Technical specifications:
• Servo Technology: Digital High Voltage
• Input Voltage (V): 6.0V - 7.4V
• Servo Type / Size: Standard
• Motor Type: Brushless Motor
• Gear Material: Metal Gears
• Ball Beared: Ball Beared
• Servo Case: Aluminium
• Speed 60°/Sec @ 7.4V: 0.048 Sec/60°
• Torque kg/cm @ 7.4V: 10.0 Kg/cm
• Length (mm): 40.3 mm
• Width (mm): 20.2 mm
• Height (mm): 38.7 mm
• Weight (g): 76 g
• Connector type: JR
• Spline size: 25T Spline

General Info

Item Nr: SB-2283MG

Barcode: 4710006992648

Brand: Savöx

Servo - Dimensions

Servo Type: Standard Servo

Spline Type: 25T Spline

Length (mm): 40,3

Width (mm): 20,2

Height (mm): 38,7

Weight (g): 76

Servo - Specs

Speed 60°/Sec @ 7.4V: 0,05

Torque kg/cm @ 7.4V: 10

Servo - Technology

Technology: Digital HV

Operating Voltage (V): 6.0V - 8.4V

Servo Motor: Brushless Motor

Servo Protection: Water - Dust Resistant

Servo Positioning: VR Potentiometer - Direct Drive

Servo Gears: Metal Gears

Servo Case: Aluminium Case

Connector: JR Universal + Colored Lead
